SUPPORTED SAMPLE RATES
44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
MICROPHONE INPUTS
- Frequency Response
20Hz - 20kHz ± 0.1dB Min Gain
20Hz - 35kHz ± 0.2dB Min Gain
- Dynamic Range
- 118dB A-weighted
- THD+N
- 0.001%
- Noise EIN
- <-128dBu A-weighted
- Maximum input level
- +18dBu at minimum gain
- Gain Range
- 57dB
LINE INPUTS 1-4 (VARIABLE GAIN)
- Frequency Response
20Hz - 20kHz ± 0.1dB Min Gain
20Hz - 35kHz ± 0.2dB Min Gain
- Dynamic Range
- 118dB A-weighted
- THD+N
- 0.001%
- Maximum input level
- +26dBu at minimum gain
- Gain Range
- 57dB
LINE INPUTS 5-8 (FIXED GAIN)
- Frequency Response
20Hz - 20kHz ± 0.1dB Min Gain
20Hz - 35kHz ± 0.2dB Min Gain
- Dynamic Range
- 118dB A-weighted
- THD+N
- 0.001%
- Maximum input level
- +18dBu at minimum gain
- Gain Range
- 57dB
INSTRUMENT INPUTS
- Frequency Response
20Hz - 20kHz ± 0.1dB Min Gain
20Hz - 35kHz ± 0.2dB Min Gain
- Dynamic Range
- 117dB A-weighted
- THD+N
- 0.001%
- Maximum input level
- +14dBu at minimum gain
- Gain Range
- 57dB
LINE & MONITOR OUTPUTS
- Dynamic Range Outputs
- 118dB A-weighted
- Maximum Output Level
- +18dBu, Balanced Line/TRS Outputs
- THD+N
- 0.0006%
HEADPHONE OUTPUTS
- Dynamic Range
- 115dB A-weighted
- THD+N
- 0.0003 % > 100R
- Maximum Output Level
- 15dBu > 100R
